HBLAC2 HWD

Name: HBLAC2 HWD
Brand: Hubbell Wiring Device-Kellems
SKU: HBLAC2 HWD
Availability: InStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Hubbell Wiring Device-Kellems

Manufacturer part number:

HBLAC2

product.name:

HBLAC2 HWD

CBT Inventory

Vendor Inventory

Availability:

Ships in 4-6 days.

Estimated dates are contingent upon manufacturer stock.

Price on Request

Description

Brand Name

Wiring Device-Kellems

Type

2-Position 3-Pole Non-Fusible Standard

Description

Wiring Device-Kellems Circuit-Lock® Switched Enclosure Auxiliary Contact, 2-Position 3-Pole Non-Fusible Standard, 250 VAC, 10 A, 1NC-1NO Contacts, For Use With: HBLDS Series 30, 60, 100 A Pilot Duty Disconnect Switch, Threaded Mounting, Composite

Application

Indoor Applications

Standards

RoHS Compliant | UL 746C | CSA Certified

Features

-40 to 67 deg C operating temperature without impact
Rated at NEMA 3R enclosure
60 Hz frequency
Screw termination
2500 W rating
10000 cycles mechanical operations
6000 cycles operations
A600 pilot duty
Molded-in or stamped on ratings
No auxiliary contact

Specifications

Amperage Rating:	10 A
Contacts:	1NC-1NO
Country of Origin:	PL
Material:	Composite
Mounting Type:	Threaded
Suitable For Use With:	HBLDS Series 30, 60, 100 A Pilot Duty Disconnect Switch
Voltage Rating:	250 V
