XPA1750 GAT

Name: XPA1750 GAT
Brand: Gates
SKU: XPA1750 GAT
Availability: InStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Gates

Manufacturer part number:

XPA1750

product.name:

XPA1750 GAT

CBT Inventory

Vendor Inventory

Availability:

Ships in 4-6 days.

Estimated dates are contingent upon manufacturer stock.

Price on Request

Description

Brand Name

Gates

Alternate Supplier #

942011750

Description

Manufactured to our exacting standards for quality, safety, and dependability. Their proprietary construction ensures unmatched load-carrying capacity paired with superior flex and stretch resistance.

Features

Flex-bonded cords are chemically forged to the belt body, providing equal load distribution and bending stress absorption without cord deterioration. Patented Ethylene construction helps resists belt cracking and provides application versatility. Proprietary construction process combines flex and load-carrying capacity with reduced stretch and superior cord adhesion properties. Ideal for use as replacements on drives that require metric cross sections in a broad range of applications, including textile mills, machine tool and food processing. Meets ARPM/RMA IP-3-2 oil and heat resistant standards and IP-3-3 static conductivity requirements. REACH and RoHS 2 compliant.

Specifications

Angle:	38
Belt Back Side:	Smooth
Belt Inside:	Notched
Belt/Slab:	Belt
Color:	Black
Construcao:	Bandless
Cord Material:	Polyester
Country of Origin:	US
Effective Length (in):	69.224
Effective Length (mm):	1758
GC Base Product:	Metric Power™ V-Belts - XPA Section
Harmonized Tariff Code:	4010.32.3000
Material:	Ethylene Elastomeric
Max Temp (°C):	+121
Max Temp (F):	+250
Min Temp (°C):	-57
Min Temp (F):	-70
Number of Ribs/Strands:	1
OC (in):	69.45
OC (mm):	1764
Proposition 65:	NO
Secao:	XPA
Sided:	Single Sided
Static Conductive:	Yes
Thickness (in):	0.34
Thickness (mm):	9
Top Width (in):	0.485
Top Width (mm):	12
Unitset (V80):	Yes
