Actual Product May Vary From Image

THQB2115 ABB

Name: THQB2115 ABB
Brand: GE
SKU: THQB2115 ABB
Availability: InStock

ASM THQB C/B 2 POLE 120/240V

Manufacturer: GE

Manufacturer part number: THQB2115

Availability: 1 in stock

Estimated dates are contingent upon manufacturer stock.

CBT - CINCINNATI	CBT - SPRINGBORO	CBT - SIDNEY
1	0	0
CBT - LEXINGTON	CBT - LOUISVILLE
0	0
Loading...

Price on Request

Qty:

Product Details

Brand Name

TEY / Q-Line (Bolt-On)

Description

Q line circuit breakers are one-inch wide per pole, compact, thermal-magnetic devices designed for residential and commercial applications. The QB breakers are bolt-on versions of the Q Line used for bolting to the bus connections of load centers and lighting panels. All Q Line circuit breakers feature Quick-make / Quick-break mechanisms, common trip bars, and easy to spot trip indication to ensure safety and reliability. Q Line breakers are available in 1, 2, and 3 pole versions, can be ordered with auxiliary contact and shunt trip accessories, and can be ordered for use in HID applications. 2115 Amps 15 A 21152231

Application

Thermal Magnetic

Standards

E11592

Features

Specifications

Amperage Rating:	15A
Connection:	14-8 kcmil / 12-8 kcmil
Country of Origin:	UKN
Frame:	Q-Line
Interrupt Rating:	10kA@120 Vac/10kA@120/240 Vac
Load Rating:	HACR
Number of Poles:	2
Sub Brand:	Q Line
Trip Range:	Non-Interchangeable
Trip Type:	LI

Resources

Spec Sheet
