Actual Product May Vary From Image

PP-8100-1 ISO

Name: PP-8100-1 ISO
Brand: Isostatic
SKU: PP-8100-1 ISO
Availability: OutOfStock

ISOSTATIC™ Oilube® 102903 Rectangular Plate, 8-1/8 in OAL x 1/2 in OAW, 1/4 in THK, SAE 841 Powdered Metal/Oil Impregnated Bronze

Manufacturer: Isostatic

Manufacturer part number: 102903

Availability: Expected Leadtime 4 days

Estimated dates are contingent upon manufacturer stock.

CBT - CINCINNATI	CBT - SPRINGBORO	CBT - SIDNEY
0	0	0
CBT - LEXINGTON	CBT - LOUISVILLE
0	0
Loading...

Price on Request

Qty:

Product Details

Brand Name

ISOSTATIC™

Description

ISOSTATIC™ Oilube® Rectangular Plate, 1/2 in Overall Width, 8-1/8 in Overall Length, 1/4 in Thickness, Flat Surface, 220 deg F, SAE 841 Powdered Metal/Oil Impregnated Bronze

Application

For heavy loads at moderate speeds or light loads at high speeds

Standards

Conflict Minerals Compliant | DFARS Compliant | REACH Compliant | RoHS Compliant

Features

Standard stock products
Product made with excess material to finish to stated nominal ID and OD dimensions
SAE 841-copper (87 to 90%), tin (8 to 9%), carbon and other elements
Powdered metal bronze vacuum impregnated with oil
Self-lubricating - when in motion oil rises to the surface for lubrication and restores itself when at rest
Effective in temperature range of 10 to 175 deg F with standard oil

Specifications

Country of Origin:	US
Material:	SAE 841 Powdered Metal/Oil Impregnated Bronze
Overall Length:	8-1/8 in
Overall Width:	1/2 in
Surface Type:	Flat
Temperature Rating:	220 deg F
Thickness:	1/4 in
