L075 HUB 19MM 6X2.8MM KW LOV

Product Details

Manufacturer:
Manufacturer part number:
68514441323
product.name:
L075 HUB 19MM 6X2.8MM KW LOV
CBT Inventory
0
Vendor Inventory
Loading...
Availability:
Ships in 2-4 days.
Estimated dates are contingent upon manufacturer stock.
Price on Request

Description

Brand Name

Lovejoy®

Type

Type L Style 1

Description

Lovejoy® Jaw Coupling Hub, Type L Style 1, L075 Coupling, 19 mm Bore, 44.45 mm Diameter Hub, 33.53 mm Hub Length, 6 mm W x 2.8 mm D Keyway, 11000 rpm Maximum, 20.83 mm Length Through Bore, 1/4-20 Screw, Sintered Iron, Metallic

Standards

ECCN EAR99

Features

  • Fail safe - will still perform if elastomer fails
  • No metal to metal contact
  • Resistant to oil, dirt, sand, moisture and grease
  • More than 850000 combinations of bore sizes

Specifications

Bore Diameter:19 mm
Country of Origin:US
Coupling Size:L075
Finish:Metallic
Hub Diameter:44.45 mm
Hub Length:33.53 mm
Keyway Size:6 mm W x 2.8 mm D
Length Through Bore:20.83 mm
Material:Sintered Iron
Maximum Speed:11000 rpm
Screw Size:1/4-20

Resources

Products Specifications

Bore Style
Bored
Brand Name
Lovejoy
Coupling Bore Size
19 mm
Coupling Size
L075
Type
Coupling Hub
