FWH-225A BSF

Name: FWH-225A BSF
Brand: Bussmann
SKU: FWH-225A BSF
Availability: OutOfStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Bussmann

Manufacturer part number:

FWH-225A

product.name:

FWH-225A BSF

CBT Inventory

Vendor Inventory

Availability:

Expected Leadtime 14 days

Estimated dates are contingent upon manufacturer stock.

Price on Request

Description

Brand Name

Bussmann

Type

Fast Acting

Alternate Supplier #

Grainger - 6F399

Description

High speed fuses provide superior protection or isolation for components such as diodes, silicon controlled rectifiers (SCRs), Gate torn-Off Thyristors (GTOs) and IGBTs and in light and heavy harsh DC traction applications as high as 4000Vdc and 10,000A. Also used for the protection of DC link/power converters. Optimized dimensions and materials allow for excellent thermal dissipation for high current cycling enviroments, or heavy duty applications.

Bussmann High Speed Fuse, Fast Acting, Series: FWH, Indicating/Non-Indicating: Non-Indicating, Rejection/Non-Rejection: Non-Rejection, 225 A, 1000 VAC/800 VDC, 200 kAIC Interrupt, 45 to 1000 Hz, Blade End Terminal, Stud Mount, Cylindrical Body Type, Single Element, Ceramic, 1.5 in Dia x 4.34 in L Body Size

Application

DC Common Bus, DC Drives, Power Converters/Rectifiers and Reduced Voltage Starters, Safety and Security Systems

Standards

CE Certified | CSA Certified | RoHS Compliant | UL File No. E56412 | UL Recognized

Features

Excellent DC performance
Low arc voltage and low energy let through
Superior cycling capability
Low watts loss
Low energy let through

Specifications

Amperage Rating:	225 A
Body Size:	1.5 in Dia x 4.34 in L
Body Type:	Cylindrical
Country of Origin:	MX
Element:	Single
Frequency Rating:	45 to 1000 Hz
Indicating/Non-Indicating:	Non-Indicating
Interrupt Rating:	200 kAIC
Material:	Ceramic
Mounting Type:	Stud
Rejection/Non-Rejection:	Non-Rejection
Series:	FWH
Terminal Type:	Blade
Voltage Rating:	1000 VAC/800 VDC
