CCMR6.25TXP LIT

Name: CCMR6.25TXP LIT
Brand: Littelfuse
SKU: CCMR6.25TXP LIT
Availability: OutOfStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Littelfuse

Manufacturer part number:

CCMR6.25TXP

product.name:

CCMR6.25TXP LIT

CBT Inventory

Vendor Inventory

Availability:

Ships in 4-6 days.

Estimated dates are contingent upon manufacturer stock.

Price on Request

Description

Brand Name

Littelfuse®

Description

CCMR series dual element, time delay fuses are recommend for space-saving protection of motor circuits upto 40 hp. Only true dual element time delay CC fuses specifically engineered for motor branch circuit protection. Provide type II protection (no damage) to both NEMA-rated and the more sensitive IEC (international Electromechanical Commission) type motor circuit components. Available in larger sizes from 35 to 60 A. No other 600 VAC fuse is available with this current carrying capacity in a package this small. Compared to other UL listed fuses, class CC dual element fuses are the most current limiting, rating for rating. Provide superior protection in a fraction of the space required by other fuse classes.

Littelfuse® POWR-GARD® Time Delay Fuse, Series: CCMR, Non-Indicating, 6.25 A, 600 VAC/250 VDC, 20/200 kA Interrupt, Class: CC, 50/60 Hz Frequency, Ferrule Terminal, Holder Mounting, Cartridge Body, Dual Element, 0.41 in Dia x 1.5 in L Body

Application

Motor and Motor Branch Circuit Protection Applications

Standards

UL 248-4 | E81895 | CSA LR29862 | CE Certified | PROP65: This product can expose you to chemicals including nickel, which is known to the State of California to cause cancer.

Features

POWR-PRO™ performance
Extremely current limiting
300 kA interrupting rating (self-certified)

Specifications

Amperage Rating:	6.25 A
Body Size:	0.41 in Dia x 1.5 in L
Body Type:	Cartridge
Class:	CC
Country of Origin:	MX
Element:	Dual
Frequency Rating:	50/60 Hz
Indicating/Non-Indicating:	Non-Indicating
Interrupt Rating:	20/200 kA
Mounting Type:	Holder
Series:	CCMR
Terminal Type:	Ferrule
Voltage Rating:	600 VAC/250 VDC
