ATQR5 FER

Name: ATQR5 FER
Brand: Mersen
SKU: ATQR5 FER
Availability: InStock

Actual Product May Vary From Image

Product Details

Manufacturer:

Mersen

Manufacturer part number:

ATQR5

product.name:

ATQR5 FER

CBT Inventory

Vendor Inventory

Availability:

Expected Leadtime 15 days

Estimated dates are contingent upon manufacturer stock.

Price on Request

Description

Brand Name

Mersen

Type

Current Limiting Low Voltage North American Time Delay

Alternate Supplier #

Grainger - 4ZCE8

Description

ATQR small dimension fuses feature time delay characteristics ideally suited for the high inrush currents of control transformers, solenoids and similar inductive loads. Mersens Amp-Trap® 2000 ATQR fuses provide superior protection for the branch circuits of electrical distribution systems.

Mersen Amp-Trap® 2000 SmartSpot® Power Fuse, Current Limiting Low Voltage North American Time Delay, Series: ATQR, Non-Indicating, Rejection, 5 A, 600 VAC, 200 kA Interrupt, Class: CC, Ferrule Terminal, Clip Mounting, Cylindrical Body, Dual Element, Fiberglass, 13/32 in Dia x 1-1/2 in L Body

Application

Control Transformer, Solenoid, Inductive Load, Lighting, Heater and General Purpose Load Application

Standards

CSA C22.2 No. 248.4 | DC Listed to UL 248 | RoHS Compliant | UL 248-4 File No. E2137

Features

Time delay for control transformer inrush loads without nuisance opening
Highly current limiting for low peak let through current
Rejection style design prevents replacement errors
High visibility orange label ensures instant brand recognition, simplifies replacement
Metal embossed date and catalog number for traceability and lasting identification
Fiberglass body provides dimensional stability in harsh industrial settings
High grade silica filler ensures fast arc quenching and high current limitation
Tin plated copper contact

Specifications

Amperage Rating:	5 A
Body Size:	13/32 in Dia x 1-1/2 in L
Body Type:	Cylindrical
Class:	CC
Country of Origin:	MX
Element:	Dual
Indicating/Non-Indicating:	Non-Indicating
Interrupt Rating:	200 kA
Material:	Fiberglass
Mounting Type:	Clip
Rejection/Non-Rejection:	Rejection
Series:	ATQR
Terminal Type:	Ferrule
Voltage Rating:	600 VAC
